Industrial Computer Built 246v Vertical Wall Printer For Flat Materials

Industrial Computer Built 246v Vertical Wall Printer For Flat Materials

Industrial Computer Built 246v Vertical Wall Printer For Flat Materials
Industrial Computer Built 246v Vertical Wall Printer For Flat Materials
Industrial Computer Built 246v Vertical Wall Printer For Flat Materials
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Industrial Computer Built In Suitable For All Flat Materials Silent Vertical UV Printer Art Robot Marketing Type: Original Product
After-sales Service: Online Support, Video Technical Support Color: CMYK+WWWW, Multicolor Auto Matching
Ink Type: Special UV Ink Painting precision: Upto 2880DPI
Usage: Glass, Ceramic Tiles, PVC Printing, Wall Printer, Card Printer, Label Printer, Fabric Printer, Metal Printer, Wood Printer, Glass Printer, Ceramic Printer, Etc
High Light:

246v vertical wall printer


usb vertical wall printer


usb 3d wall printer machine

Industrial Computer Built In Suitable for All Flat Materials Silent Vertical UV Printer Art Robot


We have 9 patents on the wall printing machine as follows:

1. Nozzle vertical movement device (practical type)

2. Wall plotter control box (practical type)

3. Cartridge constant temperature heating device (practical type)

4. Wall plotter nozzle automatic tracking device (practical type)

5. Detachable wall plotter base (practical type)

6. Multifunctional guide rail wall plotter with unlimited screen length (practical type)

7. Automatic cleaning device for the nozzle of wall plotter (practical type)

8. 3D wall-mounted printer (design)

9. Multifunctional guide rail coating machine (appearance design)


Our machines are recommended by investors and brands authoritatively recommended by CCTV1, CCTV2, CCTV4, CCTV7, CCTV9, and CCTV10.



Basic parameters
Data transmission mode USB
L*W*H (main body from ground) 80*32*239cm (height customizable)
Printhead Auto cleaning
Ink consumption 15-20ml/m2
Ink base color CMYK+WWWW
Painting precision Upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
  10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rail
Z axis guide 14cm
Spay distance 0.5-1cm
X axis effective stroke 470cm
Z axis effective stroke 10cm
Synchro belt 1pcs
Drive rack 5pcs
Net picture print height 160cm (height customizable)
Machine weight 52kg
Lead rails weight 10kg/piece*5pcs, total 50kg
Applied wall Any flat materials
Control configuration
Ink container capacity 400ml/piece
Printhead cleaning Auto
Flasing testing Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language English
Auto blank skip Y
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Special UV ink
Integrated voltage stabilizer Y
Laser positioning Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model improvement.


UV printer has widest usage among all the printers.

It call be your Wall printer, Card printer, Label printer, Fabric printer, Metal printer, Wood printer, Glass printer, Ceramic printer, etc, invest just once and you can get business from all fields. UV machine is not only your Art Robot, but aslo your money maker. Why not order one for yourself now?



All kinds of propaganda slogans, pictures... are all using this ZKMC uv wall printer directly to make. No longer the traditional practice anymore.


ZKMC uv wall printer painting costs are low, less than USD 1 per square meter. If customer only charge about USD 10/m2. It' d gain 10 times of return. Compared with the cost and profit return it is very considerable, so the vertical wall printer market prospects are very delighted.


In order to have good word of mouth propagana, first of all to buy a good machine, to be stable. In terms of the use of ZKMC vertical wall printer, with automatic intelligent painting, no typography, as long as the picture's uploaded into the laptop for printing, you could get the painted pattern and selectdc the picture exactly the same.

Special Ink Heating UV Vertical Wall Printer 0Special Ink Heating UV Vertical Wall Printer 1

Special Ink Heating UV Vertical Wall Printer 3

Special Ink Heating UV Vertical Wall Printer 4


Q1: What kind of surface can be printed on your machine?
UV printers can be widely used for painting on various surfaces, including walls of different materials, chemical fiber canvas, wallpaper, wood, metal, ceramics, rice paper, metal sheet, pvc, glass, etc.
Q2: How should we operate the machine? Is training necessary?
The operation of the machine is easy. We will provide customers with operating manuals with pictures and related videos. In addition, we will provide online video training when needed. The customer masters our machine operation within 1-3 hours. Customers can also come to our workshop for training.
