| Place of Origin: | Beijing, China |
| Brand Name: | Zhongkemeichuang |
| Certification: | CE for machine, RoHS for ink |
| Model Number: | ZK-Q8 Foldable |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 plywood box |
| Supply Ability: | 100 sets/month |
| Name: | 4d Auto Skip Blank Foldable 3.0USB 2880dpi Auto Sensor Trancing Direct To Wall Printer CE For Machine | Display Screen: | 7”LCD Touch Screen |
|---|---|---|---|
| Painting Precision: | 720---2880dpi | Printhead: | Foldable, Printhead Can Be Folded Down To Maintain More Moisture |
| Vertical Rail: | Foldable, Machine 1.4m In Height When Folded | Horizonal Rail: | Foldable, Lead Rails Width Only 22cm When Folded |
| Memory: | Either PC Or Machine Powerful Off, Machine Can Continue Print When Power On | Ultrasonic Sensors: | 2pcs |
| Auto Skip Blank: | Y | Data Transmission Mode: | USB |
| High Light: | silent vertical wall printer,4d vertical wall printer,usb 3.0 vertical wall printer |
||
4d Auto Skip Blank Foldable 3.0USB 2880dpi auto sensor trancing Direct to Wall Printer CE For Machine
How about the profit? How will You charge from Your clients? As far as we know, now in China the market price is around 10---50usd per square meter,differs according to Your local economy. Some of machine owners charge their European clients 100usd per square meter and even higher. It is really cool, cost-effective investment,a touching project.
Our fodalble machine is our new product in 2021, print head foldable, horizonal lead rails foldable, vertical rails foldable, these 3 parts foldable not only save space when transport the machine, the machine and 5 lead rails and ink all can be put in the back of a car. As You know, print head is one of the key part of the machine, just like the pen nib is key part of a pen. After You finish printing on walls, You can fold the print head, save the space, and after folded the print head the direction is facing the ground, this will make the print head avoid dust in and keep print head more moisture, can maintain the printhead longer living time.
With the promising bluesea endless market, low investment, high return profit prospects, many entrepreneurs decide to choose wall painting robots as their money maker.
Advantages:
1. Patents: In the past 8 years, ZKMC has obtained around 9 related patents regarding wall printing machine.
2. Credentials: Our products have been certified with CE for machine, RoHS for ink, and DGM Ink Air Transport.
3. Global market: Our machines are getting popular in many countries worldwide. So far, our printers have been exported to Israel, Romania, Canada, Egypt, Swiss, Sweden, Russia, and so on.
4. Local service in abroad: Customers from Russia, Belarus, Middle East... could get in touch with our sole agents there for timely consultation of ZKMC wall printing machine.
ZKMC will be your lifetime reliable partner!
| Machine configuration | |
| X axis guide | 5m rails(5 lead rails, each 1meter long, each foldable 22cm width only after be folded) |
| Y axis guide | Standard model: 219cm(the other models: 239cm, 309cm), Y axis foldable, 1.4m in height after folded |
| Z axis guide | 15cm |
| Display screen | 7’’ LCD, touch screen |
| Spay distance | 0.5-1cm |
| Print head | International brand Epson brand, print head fodable after using, which can make print head moisture and advoid dust |
| X axis effective stroke | 470cm |
| Y axis effective stroke | Standard model: 180cm (the other models: 200cm, 270cm) |
| Z axis effective stroke | 10cm |
| Synchro belt | 1pc |
| Drive rack | 5pcs |
| Net picture print height | Standard 1.8m (can tailor-made other models: 2.0m, 2.7m), unlimited width |
| Machine weight | 62kg |
| Lead rails weight | 10kg*5pcs |
| Applied wall | Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc. |
| Control configuration | |
| Ink container capacity | 400ml |
| Printhead cleaning | Auto |
| Pump test | Y |
| Stepper motor | Y |
| Level | Y |
| Painting mode | Bi-directional |
| Ultrasonic sensors | 2pcs |
| Performance configuration | |
| Language switch | Chinese, English |
|
Auto skip blank, Auto laser Positioning |
Y |
| Intelligent lifting | Support |
| Ink supply mode | Negative pressure auto ink supply |
| Color matching treatment | Auto |
| Ink use | Water based ink |
| Surface treatment | Water based varnish |
| Integrated voltage stabilizer | Y |
| Ink Heating | Y |
| Software | Professional Printer Maintop Software, ZKMC output software |
| Computer system | Windows XP, win7, win8, win10 |
| Remarks | The above data for reference only, may change due to continuous product/model upgrading. |
Q&A
Q1. What kind of ink does our machine use?
A: Special customized water based ink: CMYK 4 colors, 1 bottle/color/500ml.
Our machine is applied both indoor and outdoor wall decor, the eco friendly ink has no harm to health. It meets the public requirements for health care.
Q2. What is the difference between vertical machine and horizontal machine?
A: Vertical machine can print any width photo; while the horizontal machine can only print 1.8m*1.7m
Q3 What kind of surface your machine can print?
A: it can be widely used for painting on many kinds of vertical surfaces, professional in putty powder wall, diatom mud wall, latex paint wall, shell powder wall, chemical fiber canvas, wallpaper,wood, metal, ceramics, rice paper, etc.
Q4: How shall we assemble the machine?
A: Customer shall assemble the machine based on our video and operation manual provided. It’s easy, usually take about 15 minutes after customer becoming familiar with our machine.
Q5: How shall we operate the machine? Is training necessary?
A: The operation of the machine is easy to learn. We will provide operation manual with pictures and related videos to customer. Additionally, we’ll provide online training while needed. So, our customers could master our machine operation within within 1---3hours. Customer can also come to our workshop to get training.
Q6: What are the after sales service?
A: Our machine has 1 year warranty (ink and printhead excluded) if not artificial damaged. After the warranty, we still provide lifetime technical support and service.
Q7: What’s the delivery time?
A: About 5-10 working days after receive the payment.
