| Place of Origin: | Beijing, China |
| Brand Name: | Zhongkemeichuang |
| Certification: | CE for machine, RoHS for ink |
| Model Number: | ZK-Q7PLUS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 plywood box |
| Delivery Time: | 5-10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100 sets/month |
| Name: | 2880dpi Multifuncation Automatic Vertical Wall Printer For Interior Decoration | Application: | Schools |
|---|---|---|---|
| Showroom Location: | Egypt, Russia | Ink Type: | Special Water Based Ink |
| Ink Color: | Dual 4 Colors | Color Matching: | Auto |
| Print Dimension: | 1.8-2.7m Height, Unlimited Width | ||
| High Light: | 2880dpi Wall Digital Printing Machine,Wall Digital Printing Machine Multifunction,2880dpi Wall Printing Machine |
||
2880dpi Multifuncation Automatic Vertical Wall Printer For Interior Decoration
The vertial wall printer is easy to operate and carry with durable and excellent material. The machine is assembled from aluminum alloy with top precision. All related parts are manufactured by professional mold manufacturing process. Therefore, whole machine stability, consistency are guaranteed.
| Basic parameters | |
| Data transmission mode | USB |
| L*W*H (main body from ground) | Standard model: 70*31*239cm (the other models: 259cm, 329cm) |
| Printhead | Auto cleaning |
| Ink consumption | 8-12ml/m2 (less than USD1/m2) |
| Ink base color | Dual 4 colors (CMYK, CMYK), use special water based ink |
| Painting precision | From 720DPI, upto 2880DPI |
| Painting direction | Vertical |
| Painting speed | Multispeed adjustable, ~1-7m2/h |
| Voltage/power | 90-246V/380W,47-63HZ |
| Storage/Operation | -10℃-35℃(59°F-95°F) |
| 10%-70% relative humidity, in non-condensation state | |
| Surface tracing | Hyperbolic banner sensors, two-way induction up and down |
| Machine configuration | |
| X axis guide | 5m rails |
| Y axis guide | Standard model: 219cm (other models: 239cm, 309cm) |
| Z axis guide | 15cm |
| Display screen | 4.3’’ LCD, touch screen |
| Spay distance | 0.5-1cm |
| X axis effective stroke | 470cm |
| Y axis effective stroke | Standard model: 180cm (other models: 200cm, 270cm) |
| Z axis effective stroke | 10cm |
| Synchro belt | 1pc |
| Drive rack | 5pcs |
| Net picture print height | Standard 1.8m (other models: 2.0m, 2.7m), unlimited width |
| Machine weight | 62kg |
| Lead rails weight | 10kg/piece*5pcs, total 50kg |
| Applied wall | Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, paper, brick wall, normal white wall, canvas, etc. |
| Control configuration | |
| Ink container capacity | 400ml |
| Printhead cleaning | Auto |
| Pump test | Y |
| Stepper motor | Y |
| Level | Y |
| Painting mode | Bi-directional |
| Ultrasonic sensors | 2pcs |
| Performance configuration | |
| Language | English |
| Computer system | Windows XP, win7, win8, win10 |
| Packing | 1 plywood packing for standard model of machine, machine and inks in 1 box, total gross weight ~220kg, box dimension ~237x81x68cm |
| Remarks | The above data for reference only, may change due to continuous product/model upgrading. |
Advantages:
ZKMC wall digital printers are exported to many countries and regions. No matter what mode of trade, whether customers have import and export experience, we will be from the customer's point of view, to provide customers with professional and effective purchase programs. In addition, we work closely with industry-renowned logistics to meet the different transportation requirements of our customers. Whether by sea, air, transportation, trucks, international express mail, such as TNT, DHL, EMS, etc. We will do our best to help customers receive the machine in a timely manner, without any problems.
