2880dpi Auto Blank Skip Direct To Wall Printer 0.5-1cm Spray Distance Silent

2880dpi Auto Blank Skip Direct To Wall Printer 0.5-1cm Spray Distance Silent

2880dpi Auto Blank Skip Direct To Wall Printer 0.5-1cm Spray Distance Silent
2880dpi Auto Blank Skip Direct To Wall Printer 0.5-1cm Spray Distance Silent
2880dpi Auto Blank Skip Direct To Wall Printer 0.5-1cm Spray Distance Silent
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Unlimited Width Printing 0.5 - 1cm Spray Distance Silent Wall Printing Robot Painting Precision: Ffrom 720dpi, Up To 2880dpi
L*W*H (main body from ground): 80*32*239cm (height Customizable) Net Picture Print Height: 1.6m (height Customizable), Unlimited Width
Ink base color: CMYK+WWWW Data transmission mode: USB
Spray Distancee: 0.5-1cm Ink consumption: 15-20ml/m2
Machine Weight: 52kg Applied Wall: Inside & Outside Wall, Glass, Pvc, Ceramic Tiles, Canvas, Etc.
High Light:

2880dpi direct to wall printer


usb direct to wall printer


usb wall printing robot

2880dpi Auto blank skip Unlimited Width Printing 0.5 - 1cm Spray Distance Silent Wall Printing Robot



ZKMC 2021 new type of UV printer get many buyers' attention because it has widest usage and can bring more income for the buyers, it can print on various materials. ZKMC vertical UV printer has industrial computer built-in, with foldable vertical rail, CMYKW 5 colors plus auto-heating ink system, dual-sensor automatic induction, it has UV lamp and can dry the printings immediately. This machine can  makes the printing more vivid and realistic,can be widely used to wall printing and can paint on other materials such as glass, metal, wood,seramic etc.


Basic parameters
Data transmission mode USB
L*W*H (main body from ground) 80*32*239cm (height customizable)
Printhead Auto cleaning
Ink consumption 15-20ml/m2
Ink base color CMYK+WWWW
Painting precision Upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rail
Z axis guide 14cm
Spay distance 0.5-1cm
X axis effective stroke 470cm
Z axis effective stroke 10cm
Synchro belt 1pcs
Drive rack 5pcs
Net picture print height 160cm (height customizable)
Machine weight 52kg
Lead rails weight 10kg/piece*5pcs, total 50kg
Applied wall Any flat materials
Control configuration
Ink container capacity 400ml/piece
Printhead cleaning Auto
Flasing testing Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language English
Auto blank skip Y
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Special UV ink
Integrated voltage stabilizer Y
Laser positioning Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model improvement.




1. Free trainning, free daily real cases sharing, free market intelligence and practical advises to entrepreneurs.


2. Over 9 years experiences in printing industry. Unique, Novelty, Individuality, Stable, Efficiency.


3. Leading in high-tech New products invention and upgrading, solely reported by CCTV, broad market outlook, bring investors high profits. Precisely take the pulse of the dynamic market, investors feel assured to follow us.


4. RoHS for ink. One year warranty if not artificial damaged and lifetime maintenance.


5. Provide not only printers, but also well-designed photos. Update buyers wide range of photos including 3D photos, photo/museum quality printing.


Special Ink Heating UV Vertical Wall Printer 0Special Ink Heating UV Vertical Wall Printer 1

Special Ink Heating UV Vertical Wall Printer 3

Special Ink Heating UV Vertical Wall Printer 4



Q1: Are you a manufacturer or a trading company? Can I visit? Since 2013, we are a professional wall painting robot manufacturer, and we are the only manufacturer in China that has received authoritative reports from CCTV. Our headquarter is located in Beijing, the capital of China. A warm welcome.


Q2: Do you have patents, certificates and honors? We have 9 patents on the wall printing machine as follows:
1. Nozzle vertical movement device (practical type)
2. Wall plotter control box (practical type)
3. Cartridge constant temperature heating device (practical type)
4. Wall plotter nozzle automatic tracking device (practical type)
5. Detachable wall plotter base (practical type)
6. Multifunctional guide rail wall plotter with unlimited screen length (practical type)
7. Automatic cleaning device for the nozzle of wall plotter (practical type)
8. 3D wall-mounted printer (design)
9. Multifunctional guide rail coating machine (appearance design) We have CE certification for machines. Our machines are recommended by investors and brands authoritatively recommended by CCTV1, CCTV2, CCTV4, CCTV7, CCTV9, and CCTV10.
