Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: CE for machine, RoHS for ink
Model Number: ZK-Q7PLUS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Home Decoration CE 2880dpi Vertical Wall Printer For Interior Printing Applicable Industries: Advertising Co.
Local Service Location: Egypt, Russia L*M*H (main Body from Ground): Standard Model: 70*31*239cm (the Other Models: 259cm, 329cm)
Printhead: Auto Cleaning Ink Consumption: 8-12ml/m2 (less Than USD1/m2)
High Light:

2880dpi Vertical Wall Printer


CE Vertical Wall Printer High Resolution


bidirectional vertical wall painting machine

Home Decoration CE 2880dpi Vertical Wall Printer For Interior Printing
This vertical wall printer is installed with unique ink heat program which ensures machine to work normally in cold weather. It uses our customized special water based ink with RoHs. Its printing resolution upto 2880dpi. The machine helps our customers to achieve the best printing effects with stable performance.

Basic parameters
Data transmission mode USB
L*W*H (main body from ground) Standard model: 70*31*239cm (the other models: 259cm, 329cm)
Printhead Auto cleaning
Ink consumption 8-12ml/m2 (less than USD1/m2)
Ink base color Dual 4 colors (CMYK, CMYK), use special water based ink
Painting precision From 720DPI, upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-7m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rails
Y axis guide Standard model: 219cm (other models: 239cm, 309cm)
Y axis effective stroke Standard model: 180cm (other models: 200cm, 270cm)
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Lead rails weight 10kg/piece*5pcs, total 50kg
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, paper, brick wall, normal white wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language English
Auto blank skip N
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Special water based ink
Surface treatment after printing Water based varnish
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Packing 1 plywood packing for standard model of machine, machine and inks in 1 box, total gross weight ~220kg, box dimension ~237x81x68cm
Remarks The above data for reference only, may change due to continuous product/model upgrading.

Vertical Wall Printer Show

2880dpi Vertical Wall Printer High Resolution 0

We're at IFA 2018 International Expo, Berlin, Germany.

2880dpi Vertical Wall Printer High Resolution 1
German Media Special Report About ZKMC Vertical Wall Printer at IFA
2880dpi Vertical Wall Printer High Resolution 2
2880dpi Vertical Wall Printer High Resolution 32880dpi Vertical Wall Printer High Resolution 42880dpi Vertical Wall Printer High Resolution 52880dpi Vertical Wall Printer High Resolution 62880dpi Vertical Wall Printer High Resolution 7

Q: Why can the Q8 machine print only up to 1.8 - 2.7m?

A: For standard ZK-Q8 model, the assembled machine height (from ground) is 2.39m for net picturing painting height of 1.8m. It is the most suitable height, which can ensure our machine to be erected indoor. Besides ZK-Q8 standard model, we also have net picture painting height of 2.0m, and 2.7m with total machine height of 2.59m, and 3.29m (total height measuring from ground), respectively. Additionally, any heights can be customized based on our customer's special requirement.

Q: Why do we use water-based ink?

A: It's our customized ink with advantages below
1.Easy absorbed by the wall completely
2. Show perfect color effect on the wall
3. It would not cause the printhead block, and corrode the ink system
4. RoHS certification, satisfy the public environmental protection requirements

Kind reminding: in order to keep the final painting pictures for longer, we suggest our customer to do a coating using the crystal water varnish after the painting dry. By doing this, the final painting is not only waterproof, but also sunscreen and wear resistance. It would last for over 10 years indoor and about 5 years outdoor.

Q: Is it complicated to operate the wall printing machine?

A: No, it is automatic. Everyone can master all of skills within 1 or 2 days. No need of any professional knowledge or background.
