Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height

Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height

Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height
Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height
Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Automatic 1700mm Net Picture Printing Height Inkjet Uv Wall Printer Print Dimension: 1.7m Net Picure Printing Height, Free Width
Unique Ink Heating Program: Ensure The Uv Wall Printer Works In Winter Auto Blank Skip: Achieve High Efficiency, Low Cost
Broad Application: All Flat Materials 2 Ultrasonic Sensor: Auto Detect The Wall Flatness
High Light:

Inkjet Wall Uv Printer

,

Wall Uv Printer 1700mm

,

automatic wall inkjet printer 1700mm


Automatic 1700mm Net Picture Printing Height Inkjet Uv Wall Printer

ZKMC UV wall paint printer with unique customized un inks, full of color, durable and waterproof. No need to have wall painting master. Everyone can operate it. Additionally, there're a large number of original pictures available. After the picture printing, you can immediately get the vivid 3d printing effects.


ZKMC UV wall printer key features:

1. The height of the machine can be tailored according to customer requirements
2. The computer automatically color matching
3. The operation is simple and you can learn it quickly

Basic parameters
Data transmission mode USB
L*W*H (main body from ground) 70*31*239cm
Printhead Auto cleaning
Ink consumption 8-12ml/m2 (less than USD1/m2)
Ink base color CMYK, customzied UV ink
Painting precision From 720DPI, upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height 1.7m, unlimited width
Machine weight 71kg
Lead rails weight 10kg*5pcs
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall,
wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Z-Axis Automation Y
Level Y
Ultrasonic sensors 2pcs
Performance configuration
Language English
Painting mode Bidirectional
Auto blank skip Y
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Integrated voltage stabilizer Y
Ink Heating Y
Laser light Y
Painting Media All planar materials
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.


ZKMC UV wall printer uses Japan's original imported printerhead, can print about 8m2/h and directly sprayed on the wall to print a variety of patterns, fits both for interior background wall 3D painting and exterior advertising needs. It's American ultrasonic sensors which automatically adjusts the printing height according to the uneven wall detection, avoid damaging the printhead. It's ink cost per square meter is lower than USD 1 per square meter, but with 10 times of high returns.

Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 0


We're a top and reliable 3D Wall Printing Machine supplier in Beijing, China. Our brand Zhongkemeichuang (ZKMC) is very famous for focusing on wall printer related R&D since 2013. Choose us you won’t regret in terms of quality and after sales services. Our machine can print different pictures on various materials. It's a very new and promising business opportunity with less than USD1/m2 cost, but has 10 times of high returns.

CCTV’s 55 minutes program “I Love Inventions” reported us as the pioneer in this industry.

Our wall printer participated the expo in Berlin IFA 2018, and Moscow 2019. We’re recognized by international customers worldwide.



Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 1


The operation of the machine is easy to learn. We will provide simple operation manual with pictures and user manual of software to customers. Of course, we can also dispatch our technicist to customers's factory for training. Customer can also come to our factory to get a good training when conveniently.
Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 2Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 3Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 4Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 5Auto Blank Skip Inkjet Wall Uv Printer 1700mm Net Picture Printing Height 6
