Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing

Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing

Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing
video
Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: CE for machine, RoHS for ink
Model Number: ZK-Q8
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Zkmc Q8 Ce Certificate Automatic Vertical Wall Printing Machine Software: Professional Printer Maintop Software, ZKMC Output Software
Computer System: Windows XP, Win7, Win8, Win10 Ink Use: Customized Special Water Based Ink
Ink Supply: Negative Pressure Auto Ink Supply Display Screen: 7'' LCD, Touch Screen
High Light:

Ce Certificate Vertical Wall Printer

,

Ce Certificate Vertical Wall Printer Machine

,

Vertical Wall Printer Machine Two Way



Zkmc Q8 Ce Certificate Automatic Vertical Wall Printing Machine



3D wall painting machine can be widely used in hotels, restaurants, music halls, schools, kindergartens, image walls, ZKMC 3D wall painting machine can be at will on the wall realistic painting husband and wife wedding photos, personal photo, time and space life photos, so that the traditional decoration look and sigh! ZKMC manufactured 3D wall painting machine low cost, large profit, is a good choice for you to open a shop

.

ZKC 3D wall painting machine price is not very high, generally is several thousands of costs, so it belongs to a small venture investment project, ZKMC 3D wall painting machine market blank, is now a good choice for entrepreneurship. The operation of ZKMC 3D wall painting machine is simple, do not need any technical means, for friends who want to invest, this is a good opportunity, the opportunity is not lost, it will never come again, hasten to join ZKMC 3D wall painting machine!



Basic parameters
Data transmission mode USB
L*W*H (main body from ground) Standard model: 70*31*239cm (the other models: 259cm, 329cm)
Printhead Auto cleaning
Ink consumption 8-12ml/m2 (less than USD1/m2)
Ink base color Dual 4 colors (CMYK, CMYK), use special water based ink
Painting precision From 720DPI, upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-10m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rails
Y axis guide Standard model: 219cm(the other models: 239cm, 309cm)
Z axis guide 15cm
Display screen 7’’ LCD, touch screen
Spay distance 0.5-1cm
X axis effective stroke 470cm
Y axis effective stroke Standard model: 180cm (the other models: 200cm, 270cm)
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height Standard 1.8m (other models: 2.0m, 2.7m), unlimited width
Machine weight 62kg
Lead rails weight 10kg*5pcs
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language switch Chinese, English
Auto skip blank Y
Intelligent lifting Support
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Water based ink
Surface treatment Water based varnish
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.



With the rapid development of China's economy, in major cities, everywhere tall buildings, buy more people, decoration of people are bound to be many, and in the special construction of housing wall painting is a must, so that this is a very promising project. ZKMC manufactured 3D wall painting machine quality is excellent, you can be trusted.



ZKMC 3D wall painting machine together with decorative panels, color paint, wall clothing and other forms to achieve the artistic effect of beautifying the wall, a listing will be well received by consumers. ZKMC manufactured 3D wall painting machine affordable, everyone can afford to let you open a family to earn a family.



Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing 0Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing 1Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing 2Ce Certificate Vertical Wall Printer Machine Up And Down Two Way Sensing 3
