Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead

Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead

  • Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead
  • Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead
Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: 2880 Dpi Foldable Rails Foldable Printhead Automatic Any Photo Printing H1.4m Smart Uv Digital Wall Printing Machine Brand: ZKMC
Ink: Special Uv Ink, CMYK 4 Colors For 1-head, CMYKW 5 Colors For 2-head Rail: Foldable, Horizontal Lead Rails Width 24cm After Folding
Printhead: Foldable For 1-head Machine, Folded Down For Maintaining More Moisture Ultra Sonic Sensors: Yes, 2pcs Installed At Both Top And Bottom Of The Printhead For Auto Surfaces Tracing
High Light:

indoor digital wall printing machine

,

foldable printhead digital wall printing machine

,

foldable rails vertical wall painting machine



2880 Dpi Foldable Rails Foldable Printhead Automatic Any Photo Printing H1.4m Smart Uv Digital Wall Printing Machine



ZKMC wall printer can bring vivid mural painting to life. No matter indoor, outdoor, or diffent surfaces like tiles, glass, metal, brick, paper, etc. This foldable wall painting machine is very convenient to be moved from project to project. It'd be easily put into the car trunk because of only 1.4m height after folding. Its auto operationdoes not require the operator to any painting technical experience.



Machine configuration
X axis guide 5m rails (5 lead rails, each 1m long, each foldable 24cm width only after be folded)
Y axis guide Standard model: 219cm (height customizable), Y axis foldable, 1.4m in height after folded
Z axis guide 15cm
Display screen 7’’ LCD, touch screen
Spay distance 0.5-1cm
Printhead Printhead fodable after using (for 1-printhead machine), which can make print head moisture and advoid dust
X axis effective stroke 470cm
Y axis effective stroke Standard model: 160cm
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height Standard 1.6m
Lead rails weight 10kg*5pcs
Applied wall PVC, metal, glass, ceramic tiles, inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language English

Auto skip blank,

Auto laser Positioning

Y
Intelligent lifting Support
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Special uv ink
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.



Features



1. The pattern of painting is automatically drawn under computer control, so there is no need to worry about mistakes, the pattern effect is guaranteed.



2. Compared with lacquer painting, our machine is more efficient, and it does not need many personnel, one person one machine can work, which saves a lot of costs for investors.



3. It s a one-time investment project, only need entrepreneurs to invest a machine, after that, can make money all the time with this machine. It is low risk, suitable for entrepreneurs.



ZKMC would be your lifetime reliable partner!



Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 0Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 1

Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 2




Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 3Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 4



Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 5Indoor Digital Wall Printing Machine Foldable Rails Foldable Printhead 6

Q&A





Q1: What’s the delivery time?

A: About 5-10 working days after receive the payment.

Q2. What is the difference between vertical machine and horizontal machine?

A: Vertical machine can print any width photo; while the horizontal machine can only print 1.8m*1.7m



Q3: What are the after sales service?

A: Our machine has 1 year warranty (ink and printhead excluded) if not artificial damaged. After the warranty, we still provide lifetime technical support and service.





Q4: How shall we operate the machine? Is training necessary?

A: The operation of the machine is easy to learn. We will provide operation manual with pictures and related videos to customer. Additionally, we’ll provide online training while needed. So, our customers could master our machine operation within within 1---3hours. Customer can also come to our workshop to get training.



Q5: How shall we assemble the machine?

A: Customer shall assemble the machine based on our video and operation manual provided. It’s easy, usually take about 15 minutes after customer becoming familiar with our machine.
