ODM Vertical Wall Printer Machine

ODM Vertical Wall Printer Machine

  • ODM Vertical Wall Printer Machine
  • ODM Vertical Wall Printer Machine
ODM Vertical Wall Printer Machine
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: 2021 Launched Industrial Computer Foldable Inkjet Smart 2880dpi 2 Printheads Vertical Wall Printer 3d Effect Printing Data Transmission Mode: USB
L*W*H (main Body From Ground): 80*32*239cm (height Customizable) Printhead: Auto Cleaning
Ink Base Color: CMYK+WWWW, 5 Colors Automatic Matching Painting Precision: Upto 2880DPI
Painting Speed: Multispeed Adjustable, 1---8square Meter/h
High Light:

ODM Vertical Wall Printer Machine

,

ODM robot wall printer

,

high accuracy vertical wall printer machine

2021 Launched Industrial Computer Foldable Inkjet Smart 2880dpi 2 Printheads Vertical Wall Printer 3d Effect Printing



ZKMC invention ZKMC Vertical Wall Printing Machine is used for directly printing various individual patterns on ceramic tiles, glass, wood, metal, cement wall, brick wall, etc.



In 2021, the general direction of the market is 3D effect. The cost of the traditional manual process is quite expensive, however, the printing price of the wall printer is very friendly, ordinary people can accept and afford.



Foldable 3D effect UV vertical Printer has the widest usage in life. It is a modern high-technique product. With this lovely printing robot, you can print any picture/pattern/sentences/calligraphy/art works on walls, glass, wood, ceramic, metal box, paper, fabric etc.  You can take advantage of this modern printing machine to make good money.





Basic parameters
Data transmission mode USB
L*W*H (main body from ground) 80*32*239cm (height customizable)
Printhead Auto cleaning
Ink consumption 15-20ml/m2
Ink base color CMYK+WWWW
Painting precision Upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rail
Z axis guide 14cm
Spay distance 0.5-1cm
X axis effective stroke 470cm
Z axis effective stroke 10cm
Synchro belt 1pcs
Drive rack 5pcs
Net picture print height 160cm (height customizable)
Machine weight 52kg
Lead rails weight 10kg/piece*5pcs, total 50kg
Applied wall Any flat materials
Control configuration
Ink container capacity 400ml/piece
Printhead cleaning Auto
Flasing testing Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language English
Auto blank skip Y
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Special UV ink
Surface treatment after printing N
Integrated voltage stabilizer Y
Laser positioning Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model improvement.




ZKMC uv wall printer painting costs are low, less than USD 1 per square meter. If customer only charge about USD 10/m2. It' d gain 10 times of return. Compared with the cost and profit return it is very considerable, so the vertical wall printer market prospects are very delighted.



Special Ink Heating UV Vertical Wall Printer 0Special Ink Heating UV Vertical Wall Printer 1

Special Ink Heating UV Vertical Wall Printer 3

Special Ink Heating UV Vertical Wall Printer 4

In order to have good word of mouth propagana, first of all to buy a good machine, to be stable. In terms of the use of ZKMC vertical wall printer, with automatic intelligent painting, no typography, as long as the picture's uploaded into the laptop for printing, you could get the painted pattern and selectdc the picture exactly the same.
