Place of Origin: | Beijing, China |
Brand Name: | Zhongkemeichuang |
Certification: | RoHS for ink |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiable |
Packaging Details: | 1 plywood box |
Supply Ability: | 100 sets/month |
Name: | 2021 Launched Industrial Computer Foldable Inkjet Smart 2880dpi 2 Printheads Vertical Wall Printer 3d Effect Printing | Data Transmission Mode: | USB |
---|---|---|---|
L*W*H (main Body From Ground): | 80*32*239cm (height Customizable) | Printhead: | Auto Cleaning |
Ink Base Color: | CMYK+WWWW, 5 Colors Automatic Matching | Painting Precision: | Upto 2880DPI |
Painting Speed: | Multispeed Adjustable, 1---8square Meter/h | ||
High Light: | ODM Vertical Wall Printer Machine,ODM robot wall printer,high accuracy vertical wall printer machine |
2021 Launched Industrial Computer Foldable Inkjet Smart 2880dpi 2 Printheads Vertical Wall Printer 3d Effect Printing
ZKMC invention ZKMC Vertical Wall Printing Machine is used for directly printing various individual patterns on ceramic tiles, glass, wood, metal, cement wall, brick wall, etc.
In 2021, the general direction of the market is 3D effect. The cost of the traditional manual process is quite expensive, however, the printing price of the wall printer is very friendly, ordinary people can accept and afford.
Foldable 3D effect UV vertical Printer has the widest usage in life. It is a modern high-technique product. With this lovely printing robot, you can print any picture/pattern/sentences/calligraphy/art works on walls, glass, wood, ceramic, metal box, paper, fabric etc. You can take advantage of this modern printing machine to make good money.
Basic parameters | |
Data transmission mode | USB |
L*W*H (main body from ground) | 80*32*239cm (height customizable) |
Printhead | Auto cleaning |
Ink consumption | 15-20ml/m2 |
Ink base color | CMYK+WWWW |
Painting precision | Upto 2880DPI |
Painting direction | Vertical |
Painting speed | Multispeed adjustable, ~1-8m2/h |
Voltage/power | 90-246V/380W,47-63HZ |
Noise | Standy<20dBA, painting <50dBA |
Storage/Operation | -10℃-35℃(59°F-95°F) |
10%-70% relative humidity, in non-condensation state | |
Surface tracing | Hyperbolic banner sensors, two-way induction up and down |
Machine configuration | |
X axis guide | 5m rail |
Z axis guide | 14cm |
Spay distance | 0.5-1cm |
X axis effective stroke | 470cm |
Z axis effective stroke | 10cm |
Synchro belt | 1pcs |
Drive rack | 5pcs |
Net picture print height | 160cm (height customizable) |
Machine weight | 52kg |
Lead rails weight | 10kg/piece*5pcs, total 50kg |
Applied wall | Any flat materials |
Control configuration | |
Ink container capacity | 400ml/piece |
Printhead cleaning | Auto |
Flasing testing | Y |
Stepper motor | Y |
Level | Y |
Painting mode | Bi-directional |
Ultrasonic sensors | 2pcs |
Performance configuration | |
Language | English |
Auto blank skip | Y |
Ink supply mode | Negative pressure auto ink supply |
Color matching treatment | Auto |
Ink use | Special UV ink |
Surface treatment after printing | N |
Integrated voltage stabilizer | Y |
Laser positioning | Y |
Ink Heating | Y |
Software | Professional Printer Maintop Software, ZKMC output software |
Computer system | Windows XP, win7, win8, win10 |
Remarks | The above data for reference only, may change due to continuous product/model improvement. |
ZKMC uv wall printer painting costs are low, less than USD 1 per square meter. If customer only charge about USD 10/m2. It' d gain 10 times of return. Compared with the cost and profit return it is very considerable, so the vertical wall printer market prospects are very delighted.
In order to have good word of mouth propagana, first of all to buy a good machine, to be stable. In terms of the use of ZKMC vertical wall printer, with automatic intelligent painting, no typography, as long as the picture's uploaded into the laptop for printing, you could get the painted pattern and selectdc the picture exactly the same.
