720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine

720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine

  • 720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine
  • 720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine
720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: CE for machine, RoHS for ink
Model Number: ZK-Q8
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Zkmc 3d Automatic Vertical Surfaces Digital Wall Printing Machine Type: Inkjet Printer
Applicable Industries: Various Vertical Walls Ultrasonic Sensors: 2 Pieces, Wall Flatness Tracing Automatically
Printing Resolution: From 720dpi, 1080dpi... Up To 2880dpi Printhead: Auto Cleaning, PH Amount Can Be Added Per Needs
High Light:

720dpi Digital Wall Printing Machine

,

1080dpi Digital Wall Printing Machine

,

720dpi Print On Wall Machine



Zkmc 3d Automatic Vertical Surfaces Digital Wall Printing Machine



ZKMC Digital Wall Printing Machine can supply paint the culture wall outdoor, also can make advertisement printing outdoor. Internal and external room painting is a picec of cake for our printing machine. Our sales covered many countries and regions around the world, and major exporting countries are Israel, Sweden, Russia, Vietnam, Egypt...



What service can we provide for you?



1. One year warranty, life-long after-sales service.

2. Technican instant online support service.

3. One to one professional technical free training. We can send engineers to install the machine overseas.



Basic parameters
Data transmission mode USB
L*M*H (main body from ground) Standard model: 70*31*239cm (the other models: 259cm, 329cm)
Printhead Auto cleaning
Ink consumption 8-12ml/m2 (less than USD1/m2)
Ink base color Dual 4 colors (CMYK, CMYK), use special water based ink
Painting precision From 720DPI, upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-10m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rail
Y axis guide Standard model: 219cm(the other models: 239cm, 309cm)
Z axis guide 15cm
Display screen 7’’ LCD, touch screen
Spay distance 0.5-1cm
X axis effective stroke 470cm
Y axis effective stroke Standard model: 180cm (the other models: 200cm, 270cm)
Z axis effective stroke 10cm
Synchro belt 1pcs
Drive rack 5pcs
Net picture print height Standard 1.8m (other models: 2.0m, 2.7m), unlimited width
Machine weight 62kg
Lead rails weight 10kg*5pcs
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language switch Chinese, English
Auto skip blank Y
Intelligent lifting Support
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Water based ink
Surface treatment Water based varnish
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.



720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine 0



ZKMC at IFA 2018, Berlin, Germany



720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine 1720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine 2720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine 3720dpi Up To 2880dpi Digital Wall Printing Machine , Print On Wall Machine 4


FAQ



Q1: How is your technical support?



A1: Our English-speaking staff is available online. Also, we can use TeamViewerr to remote control your laptop for trouble shooting.





Q2: How shall I make the payment?



A2: Bank transfer which usually has not much limitation in most countries.





Q3: How is your warranty?



A3: 1-year warranty (ink and printhead excluded). Users send back defective parts and we send the new one for replacement within the warranty period.





Q4: Do you ship internationally?



A4: Yes. With strong backup of international logistic agents, we ship to almost every places in the world by sea, air, train, or truck.
