Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent

Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent

Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent
video
Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: 2 Heads Any Lenght Ground Printing 2880dpi 3D Multifunction Flatbed UV Printer L*W*H (main body from ground): 0.4m*3.34m*0.45m(Width Can Be Tailor-made)
Painting precision: Adjustable From 720 DPI To 2880DPI Y Axis Guide: Limitless
Painting Direction: Horizonal Print Heads: 2 Epson Print Heads
Ink: 5 Color UV Ink, CMYKW UV Ink, CMYK+WWWW Painting size: 0.1---2.4m Width (can Be Tailor-made)Length: Limitless
Ink Container Capacity: 400ml CMYK, 400ml WWWW Data Transmission Mode: USB 3.0
Printing Speed: 3--8㎡/h Applied Floor: Indoor And Outdoor Parking Space, Basement Floor, Squre Floor, Shopping Mall Floor Etc.
High Light:

2880dpi multifunction flatbed printer

,

multifunction flatbed printer silent

,

2880dpi digital flatbed uv printer

2 heads any length Ground Printing 2880dpi 3D Multifunction Flatbed UV Printer



Wall Printer already in market for almost ten years. How about Floor Printer? Floor Printer is like our new born baby, it is invented and produced in April 2021. If You are seeking a project total new and want grasp Your local market and even want to be our Sole Agent in Your city/ province/ country, please feel free contact us ASAP in order to lead Your market.



This multifunction flatbed UV printer can print on the ground for ground decoration, can print on parking space, can give Your driving a special , relaxed and fun feeling. Furthermore, this printer also can print on wood doors, metals, glass, ceilings etc any material surface.



The ink cost only around 1 usd per square meter, and you can charge 300---600usd from Your clients to print a stand garage 10 square meters. And for big trucks garage, You can charge higher.



ZKMC multi function gound printer is installed with Epson 2 printheads, CMYKW 5 colors.



Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 0Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 1

Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 2Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 3

Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 4





Multi-function Flatbed UV Printer(Floor Printer)



Basic Parameters New arrival time April 2021
Data transmission mode USB 3.0
Sensor amount 2 ultrasonic sensors
L*W*H(main body from ground)

0.4m*3.3m*0.4m

(Width can be tailor-made)

Painting speed 3---8㎡/h
Ink type

Standard model: special UV ink,

CMYKW 5 colors

Print head amount 2
Ink consumption 8--12 ml /㎡
Ink cost of 1㎡ Less than 1usd
Painting precision 720---2880dpi adjustable
Painting direction Horizontal
Painting size

0.1---2.4m width (can be tailor-made)

Length: limitless

Machine configuration X axis guide Tailor-made
Y axis guide limitless
Z axis guide 14cm
Display screen N
X axis effective stroke Tailor-made
Y axis effective stroke limitless
Z axis effective stroke 10cm
Synchro belt 1PCS
Drive rack N
Applied floor Indoor and outdoor parking space, basement floor, square floor, shopping mall floor, etc
Control configuration Ink container capacity CMYK 100ml*4, WWWW,100ml*4
Print head cleaning Auto
Flash test Y
Ink jet test Y
Z-Axis Automation Y
Level Y
Laser light Y
Raster N
Ultrasonic sensors 2

Performance

configuration

Language switch English, Chinese
Painting mode Bidirectional
Automatic surface tracking

Laser positioning & ultrasonic sensor,

automatic sensing ground waves

Drive motor Multi-axis high-precision serving drive motor, synchronous precise movement, accurate printing
Image processing AI intelligent image processing
Static zone calibration Y
Step calibration Y
Print head buffer N
Spray distance 0.5-1cm
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Painting media All planar materials
Integrated voltage stabilizer Y
Laser positioning Y
Magnetic induction limit N
Auto blank skip Y
Ink heating N
Power supply 220V
Power-off continue N
Photo database your own photo resource, and we can provide you some theme pictures
Remarks:The above data for reference only, may change due to continuous product/model updating.





Digital 2880dpi 3d Uv Multifunction Flatbed Printer Silent 5



ZKMC ground printer is made of high technology, suitable for any material, with strong compatibility. ZKMC wall printer has professional coloring software, which can change color anytime and anywhere, and complete full-color image at one time without additional payment, achieves the best photo printing 3d effect.
