Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine

Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine

Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine
video
Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Zkmc Year 2021 New Product 2 Printheads 7 Inch Touch Screen 52KG 2880dpi 3d Direct To Wall Printer Applicable Industries: Any Flat Materials
Ink Type: Customized Uv Ink Warranty: One Year
Printhead: 2 Printheads, Micro Piezo Printhead Base Color: CMYK+WWWW, 5 Colors
High Light:

oem 3d wall printer

,

3d wall printer zkmc

,

3d automatic vertical wall printer direct wall painting machine



Zkmc Year 2021 New Product 2 Printheads Touch Computer 52KG 2880dpi 3d Direct To Wall Printer





Advantages



1. Our print inks have an amazing 3D effect and could achieve gold, silver and jade effects. No other additional ink is needed to have these effects.

2. All of our machines are equipped with 2 ultrasonic sensors that automatically sense the flatness of the wall. So, our machine can print high quality picture on slightly curved wall.

3. It takes about 15 minutes for machine assembling. Machine is 52kg. The weight of the 5 pieces (1m/piece) of rail is 50kg. One people could operate the machine easily.





Basic parameters
Data transmission mode USB
L*W*H (main body from ground)

80*32*275cm

Printhead 2 pieces, auto cleaning
Ink consumption

15-20ml/m2

Ink base color CMYK+WWWW, use customized uv ink
Painting precision upto 2880DPI
Painting direction Vertical
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
X axis guide 5m rails
Z axis guide 14cm
Touch computer Yes, installed in machine
Spay distance 0.5-1cm
X axis effective stroke 470cm
Y axis effective stroke Standard model: 180cm (other models: 200cm, 270cm)
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height Standard 1.8m
Machine weight5 52kg
Lead rails weight 10kg/piece*5pcs, total 50kg
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, paper, brick wall, normal white wall, canvas, glass, metal, pvc, ceramic tiles, etc.
Ultrasonic sensors 2pcs
Remarks The above data for reference only, may change due to continuous product/model upgrading.



ZKMC wall inkjet printer is equipped with American ultrasonic sensors for detecting the wall tilt automatically, unique ink heating program which ensure its stable performance in cold weather, original integrated circuit chips, micro-piezoelectric printhead, etc. those improvement make our printer would get the best 3d printing effects. 5 pieces of lead rails which save space, make the transport and reconnect easily.



Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine 0Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine 1

Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine 2
Oem Zkmc 2880dpi 3d Automatic Vertical Wall Printer Direct Wall Painting Machine 3



Q&A

Q1. Can the printing size be different?

A1. Yes, ZKMC could customize different net picture printing height machine based on demand.



Q2. Can one people operation the machine?

A1. Yes, machine opeation is easy and one people would master it in 2-4 hours. No professional background needed.



Q3. Are you manufacturer?

A3. Yes, our ~900 sqm headquarter is located in industrial development zone, Touzhou, Beijing, China.
