2440dpi Digital Flatbed Uv Printer

2440dpi Digital Flatbed Uv Printer

  • 2440dpi Digital Flatbed Uv Printer
  • 2440dpi Digital Flatbed Uv Printer
2440dpi Digital Flatbed Uv Printer
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Special UV Ink CMYKW Direct To Any Planar Materials 2440dpi Multifunctional Flatbed UV Printer UV lamp series: 20 Section Uv Power Adjustable
After Warranty Service: Online Support Available UV lamp power: 390-400NM
Light intensity: 500MW/W Ink system: Refillable Cartridge System
Cooling System: Air Cooling+water Cooling Print Head: Epson I1600
High Light:

2440dpi mini uv flatbed printer

,

ZKMC digital flatbed uv printer

,

2440dpi digital flatbed uv printer





Special UV Ink CMYKW Direct To any planar materials 2440dpi Multifunctional Flatbed UV Printer





ZKMC multifunctional Flatbed UV Printer, can not only directly print any pictures on phone cases, note book or any other flat surfaces by using our special uv ink. To satisfy you various needs in any season.



We are recruiting agents all over the world. Our attentive service, quality assurance, after sales worrry free, guranteed technology maximum support, best price will make our cooperation smooth and for long time, You just need to collect some of the machines and match Your local market printing projects, and You will earn big money easy way. Let's win tomorrow with the trust of quality, the printing is fine image quality, rich color, high resolution up to 2440dpi, the printhead is imported from Japan, famous brand, the machine is solid and durable, we provide lifetime maintenance.



Small uv printer simple operation, printing.No plate making required,flatbed uv digital inkjet printer can get the printing right away.



3D equipment printing intelligent operating system,self-cleaning, automatic ink cleaning, separate heat dissipation.Automatic lifting.



Fine lines can be printed, washing logo, precise, colorful, no cutting waste, unlimited transfer fabrics and colors,Support three-dimensional and flat printing.



The digital printing press feel is soft and fast, the stretch rebound effect is good, the fastness is as high as 5 levels.



2440dpi Digital Flatbed Uv Printer 0



2440dpi Digital Flatbed Uv Printer 1




UV lamp series
20 section uv power adjustable
UV lamp power single lamp configuration 120w
UV lamp life 50000 hours
UV lamp wavelength 390-400NM
Light intensity 500MW/W
Temperature adjustment automatic on/off, 25-30℃
Software ZMKM output software, Rip
Ink system refillable cartridge system
Cooling system air cooling+water cooling
Print head Epson I1600
Print head protection Auto checking
Ink tube capacity 220ml*5
Ink reproduction Linear curve ICC calibration curve
Print color KCMY+W
Print speed High /Medium /Low adjustable
Print direction single/bi-direction
Max. print medium thickness 0-150mm
Max. print medium weight 30kg
Max. print resolution 2440*1440*720dpi
Work power 110V-220V, 50-60HZ
Port USB2.0/ USB 3.0/ TCPIP
Work environment 25-30℃, 50% humidity, no dust
Machine size 1200*1000*660mm
Packaging dimension 1300*900*1125mm
Maximum printing size A2+,400*600MM
Print head maintenance Clean the print head before using and after using, keep the print head moisture when it is not work
Computer system request Window7/ 10
Platform lifting configuration Screw rail plus linear guide rail
Positioning mode computer typesetting printing positioning
Height adjustment mode software one key control /physical keyboard control
Platform type glass platform +aluminum platform
Ink processing system Can set time for ink automatic cycling and mixing (ink colors matching),have liquid level sensor for ink cooling alarm
Transmission way X axis linear guide rail, Two linear guiderails on both sides of Y axis,equipped with double high-precision grinding lead screws
Remark above data for reference only. Data may change due to continuous product upgrading and development.



2440dpi Digital Flatbed Uv Printer 2



Q&A

1. Do you provide warranty for machine
Yes, we provide 1 year warranty for machine, printhead excluded.

2. How can I buy your machine?
You may contact us directly for machine purchasing. Or for any info needed.

3. How can I make the payment?
Currently, our company accept T/T and cash payment.
