High Accuracy Robot Wall Printer

High Accuracy Robot Wall Printer

High Accuracy Robot Wall Printer
High Accuracy Robot Wall Printer
High Accuracy Robot Wall Printer
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Smart Foldable Printhead Vertical Rail And Horizonta LCD 3d Automatic Wall Printer Robot Direct Wall Painting Machine Data transmission mode: USB
L*W*H (main body from ground): Standard Model: 70*31*239cm (machine Total Height 239cm Of Net Picture Printing Height 1.8m). Height 1.4m After Folding. Printhead: Auto Cleaning, Printhead Foldable
Noise: Standy<20dBA, Painting <50dBA Surface tracing: Hyperbolic Banner Sensors, Two-way Induction Up And Down
Marketing Type: Original Product
High Light:

high accuracy robot wall printer

,

high accuracy direct wall printing machine

,

USB robot wall printer

Smart Foldable Printhead Vertical Rail And Horizonta LCD 3d Automatic Wall Printer Robot Direct Wall Painting Machine



Key Selling Points:



2021 new developed products with unique foldable printhead, vertical rail and horizontal rails, with wheel under the machine which is very easy for moving machine from different place to another.



Basic parameters
Data transmission mode USB
L*W*H (main body from ground) Standard model: 70*31*239cm (machine total height 239cm of net picture printing height 1.8m). Height 1.4m after folding.
Printhead Auto cleaning, printhead foldable
Ink consumption 8-12ml/m2 (less than USD1/m2)
Ink base color CMYK, use special water based ink
Painting precision Up to 2880DPI
Painting speed Multispeed adjustable, ~1-10m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
  10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rail
Y axis guide Standard model: 219cm,customizable
Z axis guide 15cm
Display screen 7’’ LCD, touch screen
Spay distance 0.5-1cm
X axis effective stroke 470cm
Y axis effective stroke Standard model: 180cm,customizable
Z axis effective stroke 10cm
Synchro belt 1pcs
Drive rack 5pcs
Net picture print height Standard 1.8m,(height customizable), unlimited width
Machine weight 62kg
Lead rails weight 10kg*5pcs, rail foldable
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language switch Chinese, English
Auto skip blank Y
Intelligent lifting Support
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Water based ink
Surface treatment Water based varnish
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.




ZKMC Wall Printer is widely applied to indoor and outdoor wall decoraton fields. In the past two or three years, it's very common that many entrepreneurs choose to start their own business to buy ZKMC wall printing machine. So far, it's still very hot business in many countries.





ZKMC uv wall printer painting costs are low, less than USD 1 per square meter. If customer only charge about USD 10/m2. It' d gain 10 times of return. Compared with the cost and profit return it is very considerable, so the vertical wall printer market prospects are very delighted.



Special Ink Heating UV Vertical Wall Printer 0Special Ink Heating UV Vertical Wall Printer 1High Accuracy Robot Wall Printer 2

High Accuracy Robot Wall Printer 3

Special Ink Heating UV Vertical Wall Printer 3
