3d Foldable Rails Foldable Printhead Wall Mural Printing Machine

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine

  • 3d Foldable Rails Foldable Printhead Wall Mural Printing Machine
  • 3d Foldable Rails Foldable Printhead Wall Mural Printing Machine
3d Foldable Rails Foldable Printhead Wall Mural Printing Machine
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: CE for machine, RoHS for ink
Model Number: ZK-Q8 Foldable
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Intelligent 3D 2880dpi Foldable Rails Foldable Printhead Laser Positioning Auto Skip Blank Vertical Wall Printer Display Screen: 7”LCD Touch Screen
Ink Base Color: CMYK, Use Special Water Based Ink Color Matching Treatment: Auto
Painting Precision: 720---2880dpi Printhead: Foldable, Printhead Can Be Folded Down To Maintain More Moisture
Vertical Rail: Foldable, Machine 1.4m In Height When Folded Horizonal Rail: Foldable, Lead Rails Width Only 22cm When Folded
Memory: Either PC Or Machine Powerful Off, Machine Can Continue Print When Power On Wheels: All Direction Wheels, Easy To Move
High Light:

foldable rails mural wall printer 3d

,

foldable rails wall mural printing machine

,

foldable printhead wall mural printing machine



Intelligent 3D 2880dpi Foldable Rails Foldable Printhead laser positioning auto skip blank Vertical Wall Printer



Is it a blue sea or red sea market? Of course blue sea market. Different from opening a restaurant, clothes shop, etc traditional business you can see everywhere on the street too many competitors,ZKMC wall painting business is a high-tech high profit new promising project, a blue sea ahead of you,wait for you to explore, not many people know about this business yet, some cities even no competitors at all, do You want to be the first people in Your city to do this business? why not start now? First step leading, always leading.



At the same time, You can control Your local market, You can even be our agent in your city and run Your local market to protect Your local market and business, You can get endless business opportunities easily.



Our fodalble machine is our new product in 2021, print head foldable, horizonal lead rails foldable, vertical rails foldable, these 3 parts foldable not only save space when transport the machine, the machine and 5 lead rails and ink all can be put in the back of a car. As You know, print head is one of the key part of the machine, just like the pen nib is key part of a pen. After You finish printing on walls, You can fold the print head, save the space, and after folded the print head the direction is facing the ground, this will make the print head avoid dust in and keep print head more moisture, can maintain the printhead longer living time.



With the promising bluesea endless market, low investment, high return profit prospects, many entrepreneurs decide to choose wall painting robots as their money maker.



Advantages:



1. Patents: In the past 8 years, ZKMC has obtained around 9 related patents regarding wall printing machine.

2. Credentials: Our products have been certified with CE for machine, RoHS for ink, and DGM Ink Air Transport.

3. Global market: Our machines are getting popular in many countries worldwide. So far, our printers have been exported to Israel, Romania, Canada, Egypt, Swiss, Sweden, Russia, and so on.

4. Local service in abroad: Customers from Russia, Belarus, Middle East... could get in touch with our sole agents there for timely consultation of ZKMC wall printing machine.



ZKMC will be your lifetime reliable partner!



Machine configuration
X axis guide 5m rails(5 lead rails, each 1meter long, each foldable 22cm width only after be folded)
Y axis guide Standard model: 219cm(the other models: 239cm, 309cm), Y axis foldable, 1.4m in height after folded
Z axis guide 15cm
Display screen 7’’ LCD, touch screen
Spay distance 0.5-1cm
Print head International brand Epson brand, print head fodable after using, which can make print head moisture and advoid dust
X axis effective stroke 470cm
Y axis effective stroke Standard model: 180cm (the other models: 200cm, 270cm)
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height Standard 1.8m (can tailor-made other models: 2.0m, 2.7m), unlimited width
Machine weight 62kg
Lead rails weight 10kg*5pcs
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall, wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Stepper motor Y
Level Y
Painting mode Bi-directional
Ultrasonic sensors 2pcs
Performance configuration
Language switch Chinese, English

Auto skip blank,

Auto laser Positioning

Y
Intelligent lifting Support
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Ink use Water based ink
Surface treatment Water based varnish
Integrated voltage stabilizer Y
Ink Heating Y
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10
Remarks The above data for reference only, may change due to continuous product/model upgrading.



3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 03d Foldable Rails Foldable Printhead Wall Mural Printing Machine 1

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 23d Foldable Rails Foldable Printhead Wall Mural Printing Machine 3
3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 4

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 5

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 6

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 7

3d Foldable Rails Foldable Printhead Wall Mural Printing Machine 83d Foldable Rails Foldable Printhead Wall Mural Printing Machine 9

Q&A

Q1. What kind of ink does our machine use?

A: Special customized water based ink: CMYK 4 colors, 1 bottle/color/500ml.

Our machine is applied both indoor and outdoor wall decor, the eco friendly ink has no harm to health. It meets the public requirements for health care.

Q2. What is the difference between vertical machine and horizontal machine?

A: Vertical machine can print any width photo; while the horizontal machine can only print 1.8m*1.7m



Q3 What kind of surface your machine can print?

A: it can be widely used for painting on many kinds of vertical surfaces, professional in putty powder wall, diatom mud wall, latex paint wall, shell powder wall, chemical fiber canvas, wallpaper,wood, metal, ceramics, rice paper, etc.





Q4: How shall we assemble the machine?

A: Customer shall assemble the machine based on our video and operation manual provided. It’s easy, usually take about 15 minutes after customer becoming familiar with our machine.



Q5: How shall we operate the machine? Is training necessary?

A: The operation of the machine is easy to learn. We will provide operation manual with pictures and related videos to customer. Additionally, we’ll provide online training while needed. So, our customers could master our machine operation within within 1---3hours. Customer can also come to our workshop to get training.



Q6: What are the after sales service?

A: Our machine has 1 year warranty (ink and printhead excluded) if not artificial damaged. After the warranty, we still provide lifetime technical support and service.



Q7: What’s the delivery time?

A: About 5-10 working days after receive the payment.
