7inch Touch Screen Vertical 3d Wall Printing Machine , Wall Printing Robot

7inch Touch Screen Vertical 3d Wall Printing Machine , Wall Printing Robot

  • 7inch Touch Screen Vertical 3d Wall Printing Machine , Wall Printing Robot
  • 7inch Touch Screen Vertical 3d Wall Printing Machine , Wall Printing Robot
7inch Touch Screen Vertical 3d Wall Printing Machine , Wall Printing Robot
Product Details:
Place of Origin: Beijing, China
Brand Name: Zhongkemeichuang
Certification: RoHS for ink
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 1 plywood box
Delivery Time: 5-10 work days
Payment Terms: T/T
Supply Ability: 100 sets/month
Contact Now
Detailed Product Description
Name: Zkmc 7" Industrial Touch Screen 2880 Dpi Uv 3d Wall Printer Robot Printhead: Auto Cleaning, 1pc For Standard Model
Print Dimension: 1.7m Height (or More Per Demands), Free Width Ink Type: Special UV Ink, Customized Ink After 100 Times Of Test
Auto Blank Skip: Saves Time And Cost Painting Accurate: Upto 720*2880 DPI
High Light:

7inch Vertical 3d Wall Printing Machine

,

7inch Wall Printing Robot

,

1.7m Wall Printing Robot



Zkmc 7" Industrial Touch Screen 2880 Dpi Uv 3d Wall Printer Robot



Features

1. Up to 2880dpi high resolution, printing speed is about 1-8 square meter per hour
2. Adopt imported sensors, can detect the wall leveling situation and adjust automaticly.
3. USB 3.0 fast communication; fiber cable digital transfer;Smart and small Remote Control
4. Reduce customer's labour cost and advoid the risk to lose customer during waiting machine repairing
5. Fast assembling, easy transportation



ZKMC wall printer robot is a new model of wall printing developed by the company as the manufacturer himself. CMYK 4 kinds of ink are available, also would have more colors based on customers' demands. UV ink makes the printing possible, and boarden the application of wall printer to any kinds of materials, including ceramic tiles, metal, glass, PVC, etc.



Basic parameters
Data transmission mode USB
Painting speed Multispeed adjustable, ~1-8m2/h
Voltage/power 90-246V/380W,47-63HZ
Noise Standy<20dBA, painting <50dBA
Storage/Operation -10℃-35℃(59°F-95°F)
10%-70% relative humidity, in non-condensation state
Surface tracing Hyperbolic banner sensors, two-way induction up and down
Machine configuration
X axis guide 5m rails
Y axis guide 219cm
Z axis guide 14cm
Display screen 7’’ LCD
Spay distance 0.5-1cm
X axis effective stroke 470cm
Y axis effective stroke 170cm
Z axis effective stroke 10cm
Synchro belt 1pc
Drive rack 5pcs
Net picture print height 1.7m, unlimited width
Machine weight 71kg
Lead rails weight 10kg*5pcs
Applied wall Inside & outside putty wall, latex wall, white wall, diatom mud wall, shell powder wall,
wooden wall, paper, brick wall, canvas, etc.
Control configuration
Ink container capacity 400ml
Printhead cleaning Auto
Pump test Y
Z-Axis Automation Y
Level Y
Ultrasonic sensors 2pcs
Performance configuration
Language English
Painting mode Bidirectional
Auto blank skip Y
Ink supply mode Negative pressure auto ink supply
Color matching treatment Auto
Integrated voltage stabilizer Y
Ink Heating Y
Laser light Y
Painting Media All planar materials
Software Professional Printer Maintop Software, ZKMC output software
Computer system Windows XP, win7, win8, win10



Wall Printer Robot's advantages:



Why can you rely on ZKMC Wall Printer to start your own business?
1. Can help you to create a new experience: with advanced technology easy to integrate art into life.
2. Improve taste of your life: wall are decorated to be vivid, and artistic.
3. Simple and easy to maintain: no cumbersome installation,automatic button for operation, easy to use and maintenance.
4. Can make benefit for you for a long-term once investing: the cost of wall painting is less than the cost of wallpaper.
5. Always with new innovation: a variety of patterns to choose, you can change any pattern you like.
6. Can be widely used:in home, outdoor wall, indoor public places.
7. 1 year warranty,life-time for technical consultation.
